The Gateway Netconnect Wall Mount LIU is a modular enclosure that provides cross-connect and interconnect capabilities for splicing and terminating outdoor cables & FTTH drop cables in fiber access network. It integrates three main functions of fiber splicing, cable winding & storing, and interface management. The enclosure adopts good quality metal sheets & surface electrostatic spray technique, which is offering safety & good endurance performance. It is the ideal design for building & campus networking.
PARTS | MATERIAL | DIMENSION | REMARKS |
Metal Shelf | Alum., 1.0mm Thickness | 320x250x55mm (LxWxH) | Black or Beige |
Splice Tray | Alum., 0.6mm Thickness | 142x116x11mm (LxWxH) | 12 fibers/Tray, 2 trays Max. |
Adapter Panel | Alum., 1.5mm Thickness | 175x37mm (WxH) | 1 Panel, Black or Beige |
Cable Plug | Rubber | 28mm Diameter | For 4 Cable Entries |
Cable Saddle | Plastic | 28x24mm Inner Ring | 2 pcs, with foam sticker |
